Jet Cool Profile Core Pin
The Jet Cool Profile Core Pin is the most technically demanding product in the pin family — combining a profiled external form, internal core-forming geometry, and an integrated jet cooling channel in a single precision-machined component. It is designed for die casting zones where space is constrained, where a specific core form must be produced, and where thermal management is critical to part quality and cycle time.
Industries Served
Engineering Detail
Key Features
Three functions in one precision component: profiled external form, internal core, and jet cooling
Manufactured using multi-process precision machining: CNC, EDM, deep-hole drilling, and profile grinding
DIN 1.2344 H-13 material chosen for extreme thermal and mechanical load resistance
Fully custom-manufactured to customer drawing — no standard sizes
Nitriding applied for surface wear resistance, extending pin life in harsh casting environments
100% dimensional inspection including internal bore, external profile, and overall geometry
PVD coating applied by trusted partners with thoroughly checked results to increase wear and tear resistance and extend durability
Manufacturing Detail
Material, Finish & Customization
Use Cases
Applications
- Multi-function die zones requiring simultaneous profiling and core formation
- Constrained die geometries where separate cooling circuits are not feasible
- High-thermal-load zones in HPDC dies with complex internal features
Why Choose Vyankatesh
Key Advantages
Replaces complex multi-part assemblies with a single, more reliable component
Reduces die assembly complexity and potential leak points in the cooling circuit
Comprehensive design and manufacturing capability for complex, multi-feature pins
Quality Standard
Quality Assurance
Full CMM inspection. Profile, core bore, cooling bore, and positional relationships all verified before dispatch.
Expert Answers
Frequently Asked Questions
Need Custom Jet Cool Profile Core Pin?
Share your drawing, sample, or specification and our engineering team will provide a tailored solution with competitive pricing and reliable delivery.
