Inserts
Full-process die casting inserts — profile, HPDC, LPDC, sub insert, and prototype — manufactured from raw material to finished, coated component
Overview
What Are Inserts?
Die casting inserts are replaceable components fitted into the die body to form specific cavity features. Fixed inserts form features in the main cavity. Loose-piece (loose) inserts are designed to be removed with the casting and extracted manually, enabling undercut and re-entrant features that cannot be ejected in the die opening direction. HPDC inserts are designed for the extreme thermal and mechanical demands of high-pressure die casting. Profile inserts combine complex cavity geometry with precision ground surfaces.
Die casting inserts are the precision-machined, heat-treated components that form the cavity features in GDC, LPDC, and HPDC dies. They must maintain their dimensional accuracy and structural integrity across tens of thousands of high-temperature, high-pressure casting cycles. Vyankatesh Engineering manufactures the complete range of die casting inserts — fixed, loose-piece, profile, HPDC, sub insert, and prototype — through a strictly managed process from certified raw material to finished, inspected component.
Why Choose Vyankatesh
Benefits
From certified raw material through in-house machining and grinding, to certified hardening and nitriding. One responsible supplier, complete quality ownership.
CNC, Wire EDM, Sink EDM, and profile grinding enable any insert geometry — including fine details, sharp internal corners, and complex undercuts.
Documented CNC programs + CMM inspection ensures every insert in a batch is within specified tolerance. No dimensional drift between batches.
Vacuum hardening eliminates distortion. Multiple tempering cycles optimise hardness/toughness balance for die application.
We offer fast-track sub inserts for design validation, progressing seamlessly to production tooling — same material, same process, same quality.
Worn or damaged inserts with no drawing can be reverse-engineered from the physical component using CMM measurement and design intent reconstruction.
How We Make Them
Manufacturing Process
Every insert at Vyankatesh Engineering goes through a controlled, documented manufacturing sequence from certified raw material to finished, inspected component.
Premium AISI H-13 / DIN 1.2344 billet selected to guarantee final precision shape, size, and long-lasting quality.
Rough and semi-finish machining, drilling, and milling to near-net shape
Complex profiles, fine details, and sharp corners by Wire EDM and Sink EDM
Vacuum heat treatment with double/triple tempering for distortion-free hardening
Surface, profile, and internal grinding to final tolerances and surface finish
High-finish manual and automated polishing to ensure smooth metal flow and easy ejection
Gas nitriding for surface hardness; optional PVD hard coating for extreme wear resistance
Our Range
Inserts Products
Browse our complete range of inserts. Each product page contains full technical specifications, material information, applications, and FAQ.
Use high grade material and heat treatment makes loose inserts more durable & long life. High quality AISI H-13/DIN 1.2344 is precisely machined, ground, hardened & Nitrided. We specialize in loose piece manufacturing starting from raw material, with complete processes including machining, hardening, and coating. Precision, consistent quality, and on-time delivery define our manufacturing strength.
View Specifications
High-grade loose and fixed High-Pressure Die Casting (HPDC) inserts designed for durability and extended life. Precision machined from premium AISI H-13/DIN 1.2344 steel, hardened and Nitrided to withstand the rigorous thermal and mechanical stresses of the HPDC process.
View Specifications
Rapidly developed sub inserts for design validation, testing, and short-run casting. We offer fast turnaround times without compromising on dimensional accuracy or material quality.
View Specifications
Rapidly developed prototype inserts for design validation, testing, and short-run casting. We offer fast turnaround times without compromising on dimensional accuracy or material quality.
View SpecificationsBuying Guide
Selection Guide
Not sure which product is right for your application? Use this quick reference guide to identify the correct starting point.
| Product | Best For | Key Specification |
|---|---|---|
| Profile Insert | Complex cavity geometry, undercut features, loose-piece applications | AISI H-13; complete managed process |
| HPDC Insert | Fixed or replaceable cavity inserts in high-pressure die casting dies | H-13; vacuum hardened; CMM inspected |
| Sub Insert | Design validation, first article testing, short-run casting | Same material and process as production; fast-track schedule |
| Prototype Insert | Design validation, first article testing, short-run casting | Same material and process as production; fast-track schedule |
